Rockwell hardness tester Dakomaster

ROCKWELL HARDNESS TESTER

Rockwell and Superficial Rockwell

DAKOMASTER

CLICK HERE TO CONFIGURE YOUR SOLUTION

Motorized hardness testers for automatic cycle

The Rockwell hardness tester Dakomaster 300 is an automatic hardness tester for Rockwell, Superficial Rockwell, Brinell, Vickers, and Shore test methods in compliance with ASTM and ISO hardness standards. This hardness tester is a top-level bench hardness tester with a wide touchscreen allowing easy test planning and a clear view of results.

Test loads

From 1 to 250 kgf (From 9,807 to 2452 N)

Rockwell and superficial Rockwell ISO 6508 / ASTM E-18

HRA – HRB – HRC – HRD – HRF – HRG – HRL – HRM – HRR  /  HRN – HRT

Brinell HBWT ASTM E-103 / ISO 6506

HB 30 – HB 10 – HB 5 – HB 2,5 – MPa (F/D2)

Vickers ISO 6507 / ASTM E-92 (Indentation only)

HV1 – HV3 – HV5 – HV10 – HV15 – HV20 – HV30 – HV50 – HV100

CLICK HERE TO CONFIGURE YOUR SOLUTION

MOTORIZED HARDNESS TESTER FOR AUTOMATIC CYCLE

The Rockwell hardness tester Dakomaster 300 is an automatic hardness tester for Rockwell, Superficial Rockwell, Brinell, Vickers, and Shore test methods in compliance with ASTM and ISO hardness standards. This hardness tester is a top-level bench hardness tester with a wide touchscreen allowing easy test planning and a clear view of results.

hardness test Rockwell 1

Test loads

From 1 to 250 kgf (From 9,807 to 2452 N)

Rockwell and superficial Rockwell ISO 6508 / ASTM E-18

HRA – HRB – HRC – HRD – HRF – HRG – HRL – HRM – HRR  /  HRN – HRT

Brinell HBWT ASTM E-103 / ISO 6506

HB 30 – HB 10 – HB 5 – HB 2,5 – MPa (F/D2)

Vickers ISO 6507 / ASTM E-92 (Indentation only)

HV1 – HV3 – HV5 – HV10 – HV15 – HV20 – HV30 – HV50 – HV100

CLICK HERE TO CONFIGURE YOUR SOLUTION

ONE BUTTON HARDNESS TEST

It does all by itself: the test cycle is fully automated! Just push the start button of the hardness tester to start the measurement and read the result:

  1. contact with the specimen
  2. clamping and activation of the reference surface point
  3. preloading, loading and measurement
  4. release of the sample and return at programmed distance

The entire test cycle is completed automatically and the result immediately appears on the display.

Dakomaster and the Affri System: a high quality combination!

Like all Affri’s hardness testers, this type of hardness testing machine achieve the top level of depth accuracy, reaching the maximum measurement resolution available for Rockwell tests. Thanks to this, measurement of the real indentation is guaranteed without any external interference and in any condition.

Rockwell hardness tester button

ONE BUTTON HARDNESS TEST

Rockwell hardness tester button

It does all by itself: the test cycle is fully automated! Just push the start button of the hardness tester to start the measurement and read the result:

  1. contact with the specimen
  2. clamping and activation of the reference surface point
  3. preloading, loading and measurement
  4. release of the sample and return at programmed distance

The entire test cycle is completed automatically and the result immediately appears on the display.



Dakomaster and the Affri System: a high quality combination!

Like all Affri’s hardness testers, this type of hardness testing machine achieve the top level of depth accuracy, reaching the maximum measurement resolution available for Rockwell tests. Thanks to this, measurement of the real indentation is guaranteed without any external interference and in any condition.

AUTO-COMPENSATION OF ALL DEFLECTIONS

Rockwell hardness tester ring

When testing unstable samples or deflecting parts, the AFFRI System will follow the sample without losing contact thanks to its infinite stroke for indenter and clamping hood.

Load forces are applied through load cells and controlled in “Closed Loop” with a frequency of 1 khz, assuring perfect linearity in every range. Results are not affected by any structural deflection, misalignment or vibration.
Accurate measurements on the first test, even in extreme conditions, eliminate the need for repeated tests. The R&R data is at the top of its class.

AUTO-COMPENSATION OF ALL DEFLECTIONS

Rockwell hardness tester ring

When testing unstable samples or deflecting parts, the AFFRI System will follow the sample without losing contact thanks to its infinite stroke for indenter and clamping hood.

Load forces are applied through load cells and controlled in “Closed Loop” with a frequency of 1 khz, assuring perfect linearity in every range. Results are not affected by any structural deflection, misalignment or vibration.
Accurate measurements on the first test, even in extreme conditions, eliminate the need for repeated tests. The R&R data is at the top of its class.

THE ROCKWELL SOFTWARE

Dakomaster is ready for INDUSTRY 4.0

This Rockwell hardness tester has pre-installed software that controls the whole instrument during the entire cycle avoiding operator errors.
Dakomaster Rockwell software includes:

  1. Touchscreen 10/12″
  2. User friendly software designed by AFFRI
  3. Color highlighted results (low/ok/high)
  4. Live statistics and graph
  5. Programs of test settings
  6. Results archives
  7. Export results to: PDF, TXT, CSV, DOD, XLS and more
  8. Data enter via code bar scanning
  9. Outputs via RS232, USB and Ethernet
  10. Data exchange with management system MES
  11. Remote import of measurement settings
  12. Integrable in network

THE ROCKWELL SOFTWARE

Dakomaster is ready for INDUSTRY 4.0

This Rockwell hardness tester has pre-installed software that controls the whole instrument during the entire cycle avoiding operator errors.
Dakomaster Rockwell software includes:

  1. Touchscreen 10/12″
  2. User friendly software designed by AFFRI
  3. Color highlighted results (low/ok/high)
  4. Live statistics and graph
  5. Programs of test settings
  6. Results archives
  7. Export results to: PDF, TXT, CSV, DOD, XLS and more
  8. Data enter via code bar scanning
  9. Outputs via RS232, USB and Ethernet
  10. Data exchange with management system MES
  11. Remote import of measurement settings
  12. Integrable in network

ROCKWELL HARDNESS TESTER DAKOMASTER 300

MAIN FEATURES

Rockwell hardness tester movement

AUTOMATIC CONTACT

Automatic movement with automatic stop when contact is made with samples. Total of 300 mm of motorized vertical stroke. The approach of the head moving to the piece as opposed to the piece moving to the head allows for more accurate, stable and safe measurements.

Rockwell hardness test inside

COMPACT HEAD

The measuring head of the rockwell hardness tester DAKOMASTER 300 hardness tester is small and compact. It can easily test inside tubes with a diameter of 150 mm and above. The thin clamping hood allows testing in very small areas with high positioning accuracy.

Rockwell hardness tester Dako base

OPEN SPACE

The rockwell hardness tester wide work table base supports masses beyond 2000 kg which allows for steady hardness measurements on bulky or irregular pieces. It also offers a comfortable working base for small pieces.

THE ACCESSORIES

INDENTERS

ASTM – ISO

TEST BLOCKS

ASTM – ISO

ANVILS

Standard and custom

CLICK HERE AND CONFIGURE YOUR SOLUTION

MAIN FEARTURES

OF ROCKWELL HARDNESS TESTER DAKOMASTER 300

AUTOMATIC CONTACT

Rockwell hardness tester movement

Automatic movement with automatic stop when contact is made with samples. Total of 300 mm of motorized vertical stroke. The approach of the head moving to the piece as opposed to the piece moving to the head allows for more accurate, stable and safe measurements.

COMPACT HEAD

Rockwell hardness test inside

The measuring head of the rockwell hardness tester DAKOMASTER 300 hardness tester is small and compact. It can easily test inside tubes with a diameter of 150 mm and above. The thin clamping hood allows testing in very small areas with high positioning accuracy.

OPEN SPACE

Rockwell hardness tester Dako base

The rockwell hardness tester wide work table base supports masses beyond 2000 kg which allows for steady hardness measurements on bulky or irregular pieces. It also offers a comfortable working base for small pieces.

THE ACCESSORIES

INDENTERS

ASTM – ISO

TEST BLOCKS

ASTM – ISO

ANVILS

Standard and custom

CLICK HERE AND CONFIGURE YOUR SOLUTION

TECHNICAL SPECIFICATIONS

StandardsEN-ISO 6508-2 / EN-ISO 6507-2 / EN-ISO 6506-2 / EN-ISO 2039 / EN-ISO 868 / ASTM E-18 / ASTM E-10 / ASTM E-103 / ASTM E-92 / ASTM E-2240 / JIS
Testing base390 x 295 mm
Height Capacity0/300 mm Motorized
Depth Capacity130 mm
Preload29.4 - 98.1 N (3 - 10 kgf)
Force rangeRockwell: 588.4 - 980.7 - 1471 N (60 - 100 - 150 kgf)
Superficial Rockwell: 29.42 - 147.1 - 294.2 - 441.3 N (3 - 15 - 30 - 45 kgf)
Brinell: 49.03 - 61.29 - 98.07 - 153.2 - 245.2 - 294.2 - 306.5 - 612.9 - 1226 - 1839 N (On request 2452 N)
(5 - 6.25 - 10 - 15.6 - 25 - 30 - 31.2 - 62.5 - 125 - 187.5 kgf - On request 250 kgf)
Vickers - Knoop: 9.807 - 29.42 - 49.03 - 98.07 - 147.1 - 196 - 294.2 - 490.35 - 980.7 N (1 - 3 - 5 - 10 - 15 - 20 - 30 - 50 - 100 kgf)
Optional tests: 49 - 132 - 358 - 961 N (For plastics and rubbers as per EN-ISO 2039 std)
Shore A - D
Feasible testsRockwell: HRC - HRA - HRB - HRD - HRE - HRF - HRG - HRH - HRK - HRL - HRM - HRR
Superficiale Rockwell: HRN - HRT - HRW - HRX - HRY
Brinell HBWT: HB30 - HB10 - HB5 - HB2.5 MPa (F/D2)
Vickers - Knoop (Indentation only): HV1 - HV3 - HV5 - HV10 - HV15 - HV20 - HV30 - HV50 - HV100
Shore A - D
Load accuracyBetter than 0.05%
