INTEGRAL REVOLVER
Fully automatic hardness testing machine with test loads from 0,1 to 3000 kgf. Motorized rotating turret up to 8 positions. Rockwell, Superficial Rockwell, Brinell HBWT,…
See moreBRINELL HARDNESS MEASURMENTS ON ALL METALS AND ALLOYS, ON ANY SAMPLE SIZE
Here you will find Affri Brinell hardness testers divided by the level of automation. From simple to fully automatic and motorized hardness testers with a wide range of testing loads and entirely conform to ASTM E-10 E-103 and ISO 6506 standards.
INTEGRAL 1
Fully automatic hardness testing machine with test loads from 1 to 3000 kgf. Brinell HBW. Touchscreen PC and high level software. Large sample capabilities.
See more
LD250 / LD750
Automatic hardness testing machine with test loads from 1 to 3000 kgf. Rockwell, Superficial Rockwell, Brinell HBWT, Brinell HBW, Vickers and Knoop. Touchscreen PC and…
See more
BK30 BRINELL SCOPE
Portable digital microscope for automatic Brinell measurement indent reading conforms to ASTM E10/ISO 6506 international standards.
See more
Easy Portal 3000
utomatic CNC portal hardness tester for very big parts. Rockwell – Superficial Rockwell – Brinell – Vickers / Test loads from 0,1 to 3000 kgf
See more
Easyflag 3000
Automatic CNC radial hardness tester for very big parts. Rockwell – Superficial Rockwell – Brinell – Vickers / Test loads from 0,1 to 3000 kgf
See more
Special hardness tester Integral Wheels
Integral Wheel is a Brinell Hardness testing machine for train wheels and railway. Fully automatic Brinell test cycles up to 3000kgf with motorized turret, automatic…
See moreDO YOU WANT TO LEARN ABOUT THE BRINELL HARDNESS TEST METHOD? CLICK HERE!
Radial Brinell hardness tester with milling
Brinell HBW and Rockwell
Test loads from 10 to 3000 kgf (98.07 to 29421 N)
Testing Brinell hardness on very large samples can’t be easier! Only one start input to get the results, including the surface preparation by milling at programmable depth.
Portal Brinell hardness tester with milling
Brinell HBW and Rockwell
Test loads from 10 to 3000 kgf (98.07 to 29421 N)
Automated Brinell Hardness tester for automatic process including surface preparation, automatic Brinell indentation and automatic Brinell indentation measure, programmable XYZ displacement to reach multiple test points.
THE BRINELL HARDNESS TEST
What is the Brinell hardness test and how does it work?
The Brinell hardness test is the most used hardness testing method in foundries, forges, heat treatments, steel shops, and castings. Thanks to the wide range of testing loads and different sizes of ball indenters, the Brinell measurement can test the hardness on all metals from hard steel, Nickel alloys, Titanium alloys, and cast iron to aluminum, copper, and light metals. The most used Brinell scale to test hard metals is HBW10/3000 (HB30) and the one to test soft metals is HBW10/1000 or HBW 2.5/62.5 (HB10).
SCOPE
The Brinell testing method is an empirical indentation hardness test that can provide useful information about metallic materials. This information may correlate to tensile strength, wear resistance, ductility, and other physical characteristics of metallic materials, and may be useful in quality control and selection of materials.
PRINCIPLE OF BRINELL HARDNESS TEST METHOD
An indentation hardness test using a verified machine to force an indenter (tungsten carbide ball with diameter), under specified conditions, into the surface of the material under test. The diameter of the resulting indentation is measured after removal of the force.
The 2 steps for the principle of the Brinell test method
The general principle of the Brinell indentation hardness test consists of two steps:
Step 1 – The indenter is brought into contact with the test specimen in a direction perpendicular to the surface, and the test force is applied (Apply the test force within 1 to 8 s). The test force is held for a specified dwell time and then removed (Maintain the fully applied test force for 10 s to 15 s).
Step 2 – The diameter of the indentation is measured in at least two directions perpendicular to each other. The Brinell hardness value is derived from the mean of the diameter measurements.
The basic knowledge about this hardness test doesn’t end there. To learn more about everything related to the Brinell test method follow the link below. This will help you better understand how our products work and choose the one that best suits your needs!
WANT TO KNOW MORE ABOUT THE BRINELL HARDNESS TEST AND HOW DOES IT WORK?
