SMART SOLUTION FOR AUTO MEASUREMENTS

All hardness testers can be upgraded into WK SERIE

with probe and microscope incorporated

SMART SOLUTION FOR AUTO MEASUREMENTS

All hardness testers can be upgraded into WK SERIE with probe and microscope incorporated

UNIVERSAL HARDNESS TESTERS

Rockwell, Superficial Rockwell, Brinell and Vickers

WK SERIE

Universal hardness tester WK

250 DRM WKC

  • 3 to 250 kgf
  • Rockwell, Superficial R., Brinell and Vickers
  • Motorized electronic load cells loading system
  • Clamping system available
  • Direct reading HR and HBW

206 EX2 WK

  • 3 to 187.5 kgf
  • Rockwell, Superficial R., Brinell and Vickers
  • Dual load cells loading system
  • Clamping system available
  • Direct reading HR and HBW
Universal simple hardness test

206 EX WK

  • 3 to 31.25 kgf or 10 to 187.5kgf
  • Rockwell, Brinell and Vickers or Superficial R., Brinell and Vickers
  • Dual load cells loading system
  • Clamping system available
  • Direct reading HR and HBW

UNIVERSAL HARDNESS TESTERS

Rockwell, Superficial Rockwell, Brinell and Vickers

WK SERIE

Universal hardness tester WK

250 DRM WKC

  • 3 to 250 kgf
  • Rockwell, Superficial R., Brinell and Vickers
  • Motorized electronic load cells loading system
  • Clamping system available
  • Direct reading HR and HBW

206 EX2 WK

  • 3 to 187.5 kgf
  • Rockwell, Superficial R., Brinell and Vickers
  • Dual load cells loading system
  • Clamping system available
  • Direct reading HR and HBW
Universal simple hardness test

206 EX WK

  • 3 to 31.25 kgf or 10 to 187.5kgf
  • Rockwell, Brinell and Vickers or Superficial R., Brinell and Vickers
  • Dual load cells loading system
  • Clamping system available
  • Direct reading HR and HBW

UNIVERSAL HARDNESS TESTING SOLUTIONS
WK SERIE

WK is an accessory applicable to each hardness tester to transform them into universal hardness testers for Brinell, Vickers and Rockwell measurements. Suitable to measure any kind of component thanks to the automatic scanning of indentation by optic probe and the direct view of result on the LCD touch-screen. Data report can be created and exported.

  • Camera HD 1.2MP • Objectives 25x or 50x with 50x or 100x zoom according to objectives
  • Autofocus
  • Autolighting LED
  • Autorecognition of indentations with auto measuring
  • Automatic and manual Brinell and Vickers measures
  • HD touchscreen
  • LCD colored touchscreen 12”
  • Software multilanguages Windows 10
  • USB, Eternet and 484 ouputs
  • Archive for data, images and statistic datas
  • Removable LCD screen for portable use
Universal simple hardness tester

UNIVERSAL HARDNESS TESTING SOLUTIONS
WK SERIE

WK is an accessory applicable to each hardness tester to transform them into universal hardness testers for Brinell, Vickers and Rockwell measurements. Suitable to measure any kind of component thanks to the automatic scanning of indentation by optic probe and the direct view of result on the LCD touch-screen. Data report can be created and exported.

Universal simple hardness tester
  • Camera HD 1.2MP • Objectives 25x or 50x with 50x or 100x zoom according to objectives
  • Autofocus
  • Autolighting LED
  • Autorecognition of indentations with auto measuring
  • Automatic and manual Brinell and Vickers measures
  • HD touchscreen
  • LCD colored touchscreen 12”
  • Software multilanguages Windows 10
  • USB, Eternet and 484 ouputs
  • Archive for data, images and statistic datas
  • Removable LCD screen for portable use
Universal hardness test display

THE HEART OF AFFRI SYSTEM
Affri System assures easy and fast measurements in any conditions. The hardness tester applies preload and load in automatic succession; within seconds the result appears.

Universal hardness test tablet

WK accessory allows to make automatic tests for Brinell and Vickers scale. The automatic focus, the zoom, real magnification 25X and 50x give you perfect measurements. Check results and data on the touch-screen and export them through Windows multi language software.

Universal hardness test display

THE HEART OF AFFRI SYSTEM
Affri System assures easy and fast measurements in any conditions. The hardness tester applies preload and load in automatic succession; within seconds the result appears.

Universal hardness test tablet

WK accessory allows to make automatic tests for Brinell and Vickers scale. The automatic focus, the zoom, real magnification 25X and 50x give you perfect measurements. Check results and data on the touch-screen and export them through Windows multi language software.

DETAILS – 250 DRM (250 DRM WKC)

Automatic motorized hardness testers

250 DRM is a fast and really easy bench hardness testers with high accuracy standards. To perform the test just act on the elevating screw and bring the sample to make contact with the indenter, then push the start button activating preloading and loading in automatic succession; within seconds results appear. Load forces are electronically applied throug load cells which eliminates problems associated with dead weight systems on traditional testers. It is not affected by vibration and it doesn’t need to be leveled.

Test loads

from 3 to 250 kgf (From 29,42 to 2452 N)

Rockwell and superficial Rockwell ISO 6508 / ASTM E-18

HRA – HRB – HRC – HRD – HRF – HRG – HRL – HRM – HRR  / HRN – HRT – HRW – HRX – HRY

Brinell HBWT ASTM E-103 / ISO 6506

HBW 1/5 – HBW 1/10 – HBW 1/30 – HBW 2.5/6.25 – HBW 2.5/7.8125 – HBW 2.5/15.625 – HBW 2.5/31.25 – HBW 2.5/62.5 – HBW 2.5/187.5 – HBW 5/25 – HBW 5/31.25 – HBW 5/62.5 – HBW 5/125 – HBW 5/250

Vickers ISO 6507 / ASTM E-92 (Indentation only)

HV3 – HV5 – HV10 – HV15 – HV20 – HV30 – HV50 – HV100

Rockwell hardness tester DRMC

DETAILS – 250 DRM (250 DRM WKC)

Automatic motorized hardness testers

250 DRM is a fast and really easy bench hardness testers with high accuracy standards. To perform the test just act on the elevating screw and bring the sample to make contact with the indenter, then push the start button activating preloading and loading in automatic succession; within seconds results appear. Load forces are electronically applied throug load cells which eliminates problems associated with dead weight systems on traditional testers. It is not affected by vibration and it doesn’t need to be leveled.

Rockwell hardness tester DRMC

Test loads

from 3 to 250 kgf (From 29,42 to 2452 N)

Rockwell and superficial Rockwell ISO 6508 / ASTM E-18

HRA – HRB – HRC – HRD – HRF – HRG – HRL – HRM – HRR  / HRN – HRT – HRW – HRX – HRY

Brinell HBWT ASTM E-103 / ISO 6506

HBW 1/5 – HBW 1/10 – HBW 1/30 – HBW 2.5/6.25 – HBW 2.5/7.8125 – HBW 2.5/15.625 – HBW 2.5/31.25 – HBW 2.5/62.5 – HBW 2.5/187.5 – HBW 5/25 – HBW 5/31.25 – HBW 5/62.5 – HBW 5/125 – HBW 5/250

Vickers ISO 6507 / ASTM E-92 (Indentation only)

HV3 – HV5 – HV10 – HV15 – HV20 – HV30 – HV50 – HV100

Rockwell hardness tester EX lever

DETAILS – 206 EX (206 EX WK)

Semi-automatic hardness testers

206 EX is a fast and really easy bench hardness testers with high accuracy standards. To perform the test just act on the elevating screw and bring the sample to make contact with the indenter, then pull the lever activating preloading and loading in automatic succession; within seconds results appear. Load forces are applied through two dynamometric load cells which eliminates problems associated with dead weight systems on traditional testers. It is not affected by vibration and it doesn’t need to be leveled.

Test loads

EXS – from 3 to 45 kgf (From 29,42 to 441,5N)
EX – from 10 to 187,5 kgf (From 98,07 to 1839 N)
EX2 – from 3 to 187,5 kgf (From 29,42 to 1839 N)

Rockwell and superficial Rockwell ISO 6508 / ASTM E-18

HRA – HRB – HRC – HRD – HRF – HRG – HRL – HRM – HRR  / HRN – HRT – HRW – HRX – HRY

Brinell HBWT ASTM E-103 / ISO 6506

HBW 1/30 – HBW 2.5/15.625 – HBW 2.5/31.25 – HBW 2.5/62.5 – HBW 2.5/187.5 – HBW 5/25 – HBW 5/31.25 – HBW 5/62.5 – HBW 5/125

Vickers ISO 6507 / ASTM E-92 (Indentation only)

HV3 – HV10 – HV15 – HV30 – HV60 – HV100

DETAILS – 206 EX (206 EX WK)

Semi-automatic hardness testers

206 EX is a fast and really easy bench hardness testers with high accuracy standards. To perform the test just act on the elevating screw and bring the sample to make contact with the indenter, then pull the lever activating preloading and loading in automatic succession; within seconds results appear. Load forces are applied through two dynamometric load cells which eliminates problems associated with dead weight systems on traditional testers. It is not affected by vibration and it doesn’t need to be leveled.

Rockwell hardness tester EX lever

Test loads

EXS – from 3 to 45 kgf (From 29,42 to 441,5N) EX – from 10 to 187,5 kgf (From 98,07 to 1839 N) EX2 – from 3 to 187,5 kgf (From 29,42 to 1839 N)

Rockwell and superficial Rockwell ISO 6508 / ASTM E-18

HRA – HRB – HRC – HRD – HRF – HRG – HRL – HRM – HRR  / HRN – HRT – HRW – HRX – HRY

Brinell HBWT ASTM E-103 / ISO 6506

HBW 1/30 – HBW 2.5/15.625 – HBW 2.5/31.25 – HBW 2.5/62.5 – HBW 2.5/187.5 – HBW 5/25 – HBW 5/31.25 – HBW 5/62.5 – HBW 5/125

Vickers ISO 6507 / ASTM E-92 (Indentation only)

HV3 – HV10 – HV15 – HV30 – HV60 – HV100

EXTRA FEATURES

L.I.S.A – Laser Indicator System Affri (Patented)

Exclusive application which allows ultra-precise test positioning. The dual laser pointing system helps to define the indentation area and distance before the contact between the indenter and the specimen. Reach extreme points with lack of illumination, edges of gear’s teeth or sides of cutting tools and blades. (This application is optional)

SAMPLE ILLUMINATION BY LED

Adjustable LED light source for a clear view of the test zone on any surface or specimen shape. Illuminate extreme points where lighting is low like sample holes and dark layers. The adjustable arm of the light can be bent in any direction allowing illumination outside of the testing area. (LED light is optional)

EXTRA FEATURES

Rockwell hardness tester DRMC laser

L.I.S.A – Laser Indicator System Affri (Patented)

Exclusive application which allows ultra-precise test positioning. The dual laser pointing system helps to define the indentation area and distance before the contact between the indenter and the specimen. Reach extreme points with lack of illumination, edges of gear’s teeth or sides of cutting tools and blades. (This application is optional)

SAMPLE ILLUMINATION BY LED

Adjustable LED light source for a clear view of the test zone on any surface or specimen shape. Illuminate extreme points where lighting is low like sample holes and dark layers. The adjustable arm of the light can be bent in any direction allowing illumination outside of the testing area. (LED light is optional)

TECHNICAL SPECIFICATIONS

ROCKWELL HARDNESS TESTERS DRM EX RT MODELS

Rockwell hardness tester DRMC

250 DRM

Motorized
Electronic Load Cell
Rockwell & Rockwell Superficial
Depth capacity 190mm
Height capacity 215mm

250 DRMC

As 250 DRM plus Brinell

Rockwell hardness tester EX2

206 EX2

Digital Semi-automatic
Dynamometric load cell
Rockwell and Rockwell Superficial
Depth Capacity 190mm
Height Capacity 215mm

206 EX2 (R+B)

As 206 EX2 plus Brinell

Rockwell hardness tester EX

206 EX

Digital Semi-automatic
Dynamometric load cell
Rockwell and Brinell
Depth Capacity 190mm
Height Capacity 215mm

206 EXS

Rockwell Superficial and Brinell

Rockwell hardness tester analogical RT

206 RTS

Analogical Semi-automatic
Dynamometric load cell
Rockwell and Brinell
Depth Capacity 190mm
Height Capacity 215mm

206 RTS

Rockwell Superficial and Brinell
