DIGITAL SHORE HARDNESS TESTER
Portable digital Hardness Tester for plastic and rubber
ELECTRONIC SHORE
DIGITAL HARDNESS TESTER ELECTRONIC SHORE
for rubbers and plastics
Shore A – B – C – D – D0 – 0 – 00 – E – M – 000 – 000S
Hardness tester Shore conforms to ASTM 2240, ASTM 1414, ISO 7619, ISO 868 standards.
The AFFRI Electronic Shore hardness tester has a slim measuring nose to ensure exact measurement also on small components. It is suitable for Shore hardness test on tires, soft flexible rubber, plastic, PVC, polyester, neoprene, leather, Thiokol, nitrile rubbers, etc.
Operating console with LCD screen. Measure at peak / at time / Continuous, store and number of tests, automatic average, list of stored results, statistic, standard deviation, histogram. Data output for computer or printer connection RS 232 C or USB.
BENCH-TOP
stand support
Bench stand support (Art. 13) for extremely precise hardness testing. The force is applied perpendicularly to the sample surface with high stability at any dwell time.
The constant pressure from the top assures a very accurate measurement. Very easy mounting of the probe on the stand support, just screw-unscrew. Supplementary weight for Shore C-D-DO are available.
DIGITAL HARDNESS TESTER ELECTRONIC SHORE
for rubbers and plastics
Shore A – B – C – D – D0 – 0 – 00 – E – M – 000 – 000S
Hardness tester Shore conforms to ASTM 2240, ASTM 1414, ISO 7619, ISO 868 standards.
The AFFRI Electronic Shore hardness tester has a slim measuring nose to ensure exact measurement also on small components. It is suitable for Shore hardness test on tires, soft flexible rubber, plastic, PVC, polyester, neoprene, leather, Thiokol, nitrile rubbers, etc.
Operating console with LCD screen. Measure at peak / at time / Continuous, store and number of tests, automatic average, list of stored results, statistic, standard deviation, histogram. Data output for computer or printer connection RS 232 C or USB.
BENCH-TOP stand support
Bench stand support (Art. 13) for extremely precise hardness testing. The force is applied perpendicularly to the sample surface with high stability at any dwell time.
The constant pressure from the top assures a very accurate measurement. Very easy mounting of the probe on the stand support, just screw-unscrew. Supplementary weight for Shore C-D-DO are available.
DESIGNED FOR OPERATOR EXPERIENCE
HIGH QUALITY FOR LASTING RELIABILITY
- 100% made in Italy
- Tungsten carbide indenter for maximum efficiency over the time
- Robust and resistant in every test condition
- R&R high performance
- Interchangeable probes with easy plug/unplug
- Accurate and fast test on small and large samples
- The ergonomic probe can be used in any direction, even upside down
- The tester can be installed on the manual or motorized bench support for laboratory purpose
HOW DOES THE ELECTRONIC SHORE WORK?
It is extremely easy to use: just push the probe on the surface of the
sample and wait for the dwell time till the result appears on the display!
HIGH QUALITY FOR LASTING RELIABILITY
- 100% made in Italy
- Tungsten carbide indenter for maximum efficiency over the time
- Robust and resistant in every test condition
- R&R high performance
- Interchangeable probes with easy plug/unplug
- Accurate and fast test on small and large samples
- The ergonomic probe can be used in any direction, even upside down
- The tester can be installed on the manual or motorized bench support for laboratory purpose
HOW DOES THE ELECTRONIC SHORE WORK?
It is extremely easy to use: just push the probe on the surface of the
sample and wait for the dwell time till the result appears on the display!
FROM PORTABLE TO BENCH-TOP
Bench stand support for extremely precise hardness testing. The force is applied perpendicularly to the sample surface with high stability at any
dwell time. The constant pressure from the top assures a very accurate measurement. Very easy mounting of the probe on the stand support, just
screw-unscrew. Supplementary weight for Shore C-D-DO are available.
MANUAL BENCH SUPPORT
ART 13
Height capacity 50 mm
Depth capacity 50 mm
MOTORIZED BENCH SUPPORT
DMG 03
Height capacity 75 mm
Depth capacity 50 mm
MAIN FEATURES
THE SOFTWARE
Intuitive keyboard with IP 64 protection. Measure at peak / at time / continuous. Measure of temperature. Automatic average, list of stored result, statistics and standard deviation. RS 232 C data out-put or USB.
MICRO PROBE
When testing inside rings or gaskets it is necessary to use a specific probe to allow internal surface testing. For this measurements we designed the Micro probe Shore A for easy inside tests. Min 45 mm Ø.
O-RINGS ASTM 1414
Set of clamping holders for very precise hardness testing on O-Rings in compliance with ASTM 1414. Sections Ø 1 – 1.79 – 2.62 – 3.53 – 5.33 – 6.99 mm, other on request.
MAIN FEATURES
THE SOFTWARE
Intuitive keyboard with IP 64 protection. Measure at peak / at time / continuous. Measure of temperature. Automatic average, list of stored result, statistics and standard deviation. RS 232 C data out-put or USB.
MICRO PROBE
When testing inside rings or gaskets it is necessary to use a specific probe to allow internal surface testing. For this measurements we designed the Micro probe Shore A for easy inside tests. Min 45 mm Ø.
O-RINGS ASTM 1414
Set of clamping holders for very precise hardness testing on O-Rings in compliance with ASTM 1414. Sections Ø 1 – 1.79 – 2.62 – 3.53 – 5.33 – 6.99 mm, other on request.
SHORE PROBES AVAILABLE
SHORE (ISO 7619 / ASTM E2240)
- Shore A – ASTM E2240 – ISO 7619 – Frustum 35° – Soft surfaces, flexible rubber, natural rubber, plastic, PVC, polyester, neoprene, leather, nitrile rubbers, tires, etc
- Shore D – ASTM E2240 – ISO 7619 – Cone 30° – Hard and rigid surfaces, ceramic and composites, acrylics, plexiglass, print rolls, cellulose, acetates, nylon, etc
- Shore B – ASTM E2240 – Cone 30° – Medium values. As A scale for higher values.
- Shore C – ASTM E2240 – Frustum 35° – Medium-hard values. As D scale for lower values.
- Shore DO – ASTM E2240 – Ball 1.2 mm – From medium-hard to hard values. As B and C.
- Shore O – ASTM E2240 – Ball 1.2 mm – Low values and very flexible materials. As A scale for low values.
- Shore OO – ASTM E2240 – Ball 1.2 mm – Very soft rubbers, sponges, expanded rubber, foam rubber, natural rubber and silicon
- Shore E – ASTM E2240 – Ball 2.5 mm – Very soft rubbers, natural rubber, elastomers, casting resin, soft PVC, leather, etc.
- Shore M – ASTM E2240 – Cone 30° – As A scale, for thin specimens and elastomer materials.
- Shore 000 – ASTM E2240 – Ball 6.35 mm – Ultra-soft rubbers, sponges, expanded rubber, foam rubber, natural rubber and silicon.
- Shore 000-S – ASTM E2240 – Ball 10.7 mm – Ultra-soft rubbers, viscoelastic polymers.
| SHORE (ISO 7619 / ASTM E2240) | |||
|---|---|---|---|
| Shore A | ASTM E2240 ISO 7619 | Frustum 35° | Soft surfaces, flexible rubber, natural rubber, plastic, PVC, polyester, neoprene, leather, nitrile rubbers, tires, etc |
| Shore D | ASTM E2240 ISO 7619 | Cone 30° | Hard and rigid surfaces, ceramic and composites, acrylics, plexiglass, print rolls, cellulose, acetates, nylon, etc |
| Shore B | ASTM E2240 | Cone 30° | Medium values. As A scale for higher values. |
| Shore C | ASTM E2240 | Frustum 35° | Medium-hard values. As D scale for lower values. |
| Shore DO | ASTM E2240 | Ball 1.2 mm | From medium-hard to hard values. As B and C. |
| Shore O | ASTM E2240 | Ball 1.2 mm | Low values and very flexible materials. As A scale for low values. |
| Shore OO | ASTM E2240 | Ball 1.2 mm | Very soft rubbers, sponges, expanded rubber, foam rubber, natural rubber and silicon |
| Shore E | ASTM E2240 | Ball 2.5 mm | Very soft rubbers, natural rubber, elastomers, casting resin, soft PVC, leather, etc. |
| Shore M | ASTM E2240 | Cone 30° | As A scale, for thin specimens and elastomer materials. |
| Shore 000 | ASTM E2240 | Ball 6.35 mm | Ultra-soft rubbers, sponges, expanded rubber, foam rubber, natural rubber and silicon. |
| Shore 000-S | ASTM E2240 | Ball 10.7 mm | Ultra-soft rubbers, viscoelastic polymers. |
